Parameter

参数

Outer Dimension(mm)外部尺寸

length×width×height:9,250*2,600*3,572

The dimension will be adjusted according to the tractor specification

可根据牵引车参数调整

Capacity(m³) 容积

33 m³

Tare Weight（kg）自重

11,000kg(+/- 5%)

Payload （kg）载重

50,000

Fabric

材质

Main Beam(mm)

纵梁

Submerged arc welding, VICT700L High-reinforced steel (equivalent to DOMEX 600)

埋弧焊，VICT700L高强钢（相当于 DOMEX 600）

Body(mm)

厢体

Floor: 6; Side wall: 3; High-reinforced/wear-resistant steel (equivalent to HARDOX 450/400)

底6，边3，NM450/宝钢欧标耐磨钢

Configuration

配置

Tire

轮胎

type: 315/80R22.5-18PR, equip 13pcs per chassis including one spare tyre. China famous brand

规格：315/80R22.5，每辆车配备13条含1条备胎；中国知名品牌轮胎

Axle

车轴

Fuwa 13T，3 sets，without ABS, optioned by factory

Fuwa 13吨级，三轴，无ABS，工厂标配

Suspension

悬挂

Enforced Tri -axle mechanical suspension

三轴加强型机械悬挂。

Hydraulic System

液压系统

HYAV 50T high quality hydraulic system

海沃HYVA 50T高品质液压系统

Landing Gear

支腿

Goldstone 30T， Lifting capacity 30T and static load 80T.

联动,动载30吨，静载80吨，自卸半挂专用支腿

Kingpin

牵引销

3.5”JOST ,exchangeable

JOST，90#，装配式

Brake System

制动系统

Dual air brake system, 30/30 type, with brake valve.

气式制动，后两轴双腔，标配紧急制动阀

ABS

辅助刹车系统

Non

无

Electrical System

电器系统

24V, LED lamp

24V，LED灯具

Spare Tire Carrier

备胎架

equip 2 set per chassis

每车配备2套

Tool Box

工具箱

1 set

1件

Paint

油漆

primer + top coat, international famous brand polyurethane paint

底漆+面漆，进口品牌聚氨酯防腐漆

Color

颜色

By customer’s requirement.

根据客户要求定制
